X2 - Vertical Windlass

Invia Ordine

[11857] Maniglia per verricello Lofrans', alluminio anodizzato, con fermo e impugnatura speciale, 20 cm, ner

[72907] Lofrans, maniglia winch galleggiante, senza fermo - 25cm

[11857] Maniglia per verricello Lofrans', alluminio anodizzato, con fermo e impugnatura speciale, 20 cm, ner

[72907] Lofrans, maniglia winch galleggiante, senza fermo - 25cm

[197977] Lofrans Motor cover for X2 -1000/1500W

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474023] KIT F FINGER X2

[601047] KIT F FINGER X2

[474053] KIT S SENSORE&MAGNETE X1/X2/X3

[601368] KIT PRIGIONIERO M8X75 #292A

[630661] ALBERO X2 #917A

[630662] ALBERO X2 #919A

[630840] SEEGER DIA.25 X2 #550

[630949] Lofrans' Barbotin X2/PRJ1000 8mmISO4565/DIN766 #916B

[630951] Lofrans' Barbotin X2/PRJ1000 10mmISO4565 #916C

[630953] Lofrans' Barbotin X2/PRJ1000 6mmISO4565/DIN766 #916A

[630955] Lofrans' Barbotin X2/PRJ1000 10mmDIN766 #916D

[631231] BASE X2 #904B ALU TRI

[631234] BASE X2 #904A CRO TRI

[631357] COPERCHIO X2 #908A CRO

[631359] COPERCHIO X2 #908B ALU

[631463] CAMPANA X2 #957 ALU

[631466] CAMPANA X2 #914A CRO

[631513] CANOTTO X2 #922

[631525] Corona dentata X2 #926

[631651] Corpo Riduttore X2 #928 ALU

[631742] CUSCINETTO 6005 2RS #966

[631745] CUSCINETTO 6008 2RS #870

[631751] CUSCINETTO 6203 #309

[631764] CUSCINETTO 51105 #311

[631795] INNESTO FRONTALE X2 #925

[631841] DISCO FRIZIONE X2 #915

[631899] DISTANZIALE X2 #958

[632063] FLANGIA X2 #920

[633245] GUARNIZIONE X2 #967

[633523] Motore elettrico 12V-3M 1,0KW B14 #1244A

[633524] Motore elettrico 24V-3M 1,0KW B14 #1244B

[633525] Motore elettrico 12V-3M 1,5KW B14 #1250A

[633526] Lofrans Motore X2-X3 24V 1,5KW B14 Circle Flange #1250B

[633537] MOLLA X2 #924

[634826] Rondella X2 #923

[635267] STACCACATENA PROJECT 1000 / X2 #910 NEW DESIGN

[635311] Spina cilindrica DIN7 4x14 A4 #887

[635378] SUPPORTO STACCACATENA X2 #911

[635490] VOLANTINO X2 #956 CRO

[635512] COPRIBARBOTIN X2 #918A CRO

[635516] VOLANTINO X2 #912 CRO

[635677] Vite senza fine A1, M=1.25 Z=55, #1308a

[635678] Vite senza fine A2, M=1.75, #1308b

[635677] Vite senza fine A1, M=1.25 Z=55, #1308a

[635678] Vite senza fine A2, M=1.75, #1308b

[72038] KIT MANUTENZIONE X2-PROJECT 1000

[72039] KIT MANUTENZIONE X2 ALU

Carateristiche principali

Mettiti in contatto

Description	Interruttore magnetotermico	Materiale	Barbotin per catena	Barbotin per cima	Velocità di recupero a carico (m/min)	Velocità Max. di recupero	Tiro Massimo Istantaneo	Tipo di motore	Peso netto	Tensione	Tipo	Assorbimento di corrente (A)	Carico di lavoro Massimo al sollevamento
VER. V. X2 CRO 1500W/12V 10DIN766	187333	Bronzo cromato	10 mm, DIN 766	-	17 m/min	40 m/min	1200 kg	1500 W	24 kg	12 V	basso profilo	130	165
VER. V. X2 CRO B+C 1500W/12V 10DIN766	187333	Bronzo cromato	10 mm, DIN 766	-	17 m/min	40 m/min	1200 kg	1500 W	25 kg	12 V	con campana	130	165
VER. V. X2 CRO B+C 1500W/24V 10DIN766	187332	Bronzo cromato	10 mm, DIN 766	-	19 m/min	40 m/min	1270 kg	1500 W	25 kg	24 V	con campana	65	175
VER. V. X2 ALU 1000W/12V 8-5/16"BBB-5/16"HT	187333	Alluminio	8 mm, ISO 4565/DIN 766	14mm, 3 legnoli	20 m/min	40 m/min	1000 kg	1000 W	19 kg	12 V	basso profilo	117	150
VER. V. X2 ALU 800W/12V 8-5/16"BBB-5/16"HT	187332	Alluminio	8 mm, ISO 4556/DIN 766	14mm, 3 legnoli	26 m/min	35 m/min	850 kg	800 W	18 kg	12 V	basso profilo	110	115
VER. V. X2 ALU B+C 800W/12V 8-5/16"BBB-5/16"HT	187332	Alluminio	8 mm, ISO 4556/DIN 766	14mm, 3 legnoli	26 m/min	35 m/min	850 kg	800 W	19 kg	12 V	con campana	110	115
VER. V. X2 ALU B+C 1000W/24V 8-5/16"BBB-5/16"HT	187332	Alluminio	8 mm, ISO 4556/DIN 766	14mm, 3 legnoli	23 m/min	40 m/min	1060 kg	1000 W	24 kg	24 V	con campana	59	160
VER. V. X2 ALU B+C 1000W/12V 8-5/16"BBB-5/16"HT	187333	Alluminio	8 mm, ISO 4556/DIN 766	14mm, 3 legnoli	20 m/min	40 m/min	1000 kg	1000 W	20 kg	12 V	con campana	117	150
VER. V. X2 CRO 800W/12V 8-5/16"BBB-5/16"HT	187332	Bronzo cromato	8 mm, ISO 4556/DIN 766	14mm, 3 legnoli	26 m/min	35 m/min	850 kg	800 W	21 kg	12 V	basso profilo	110	115
VER. V. X2 CRO B+C 800W/12V 8-5/16"BBB-5/16"HT	187332	Bronzo cromato	8 mm, ISO 4556/DIN 766	14mm, 3 legnoli	26 m/min	35 m/min	850 kg	800 W	23 kg	12 V	con campana	110	115
VER. V. X2 CRO B+C 1000W/12V 10 3/8 HT	187333	Bronzo cromato	10mm iso 4565	-	20 m/min	40 m/min	1000 kg	1000 W	24 kg	12 V	con campana	117	150
VER. V. X2 CRO 1000W/12V 10 3/8 HT	187333	Bronzo cromato	10mm iso 4565	-	20 m/min	40 m/min	1000 kg	1000 W	23 kg	12 V	basso profilo	117	150
VER. V. X2 CRO B+C 1000W/12V 8-5/16"BBB-5/16"HT	187333	Bronzo cromato	8 mm, ISO 4565/DIN 766	14 mm, 3-strand	20 m/min	40 m/min	1000 kg	1000 W	24 kg	12 V	con campana	117	150
VER. V. X2 CRO 1000W/12V 8-5/16"BBB-5/16"HT	187333	Bronzo cromato	8 mm, ISO 4565/DIN 766	14 mm, 3-strand	20 m/min	40 m/min	1000 kg	1000 W	23 kg	12 V	basso profilo	117	150
VER. V. X2 CRO 1000W/24V 10DIN766	187332	Bronzo cromato	10 mm din 766	-	23 m/min	40 m/min	1060 kg	1000 W	23 kg	24 V	basso profilo	59	160
VER. V. X2 CRO B+C 1000W/24V 10DIN766	187332	Bronzo cromato	10 mm din 766	-	23 m/min	40 m/min	1060 kg	1000 W	24 kg	24 V	con campana	59	160
VER. V. X2 CRO B+C 1000W/24V 8-5/16"BBB-5/16"HT	187332	Bronzo cromato	8 mm, ISO 4565/DIN 766	14mm 3 legnoli	23 m/min	40 m/min	1060 kg	1000 W	24 kg	24 V	con campana	59	160
VER. V. X2 CRO 1000W/24V 10 3/8 HT	187332	Bronzo cromato	10 mm, ISO 4565	-	23 m/min	40 m/min	1060 kg	1000 W	23 kg	24 V	basso profilo	59	160
VER. V. X2 ALU 1000W/12V 10 3/8 HT	187332	Alluminio	10 mm, ISO 4565	-	20 m/min	40 m/min	1000 kg	1000 W	19 kg	12 V	basso profilo	117	150
VER. V. X2 ALU B+C 800W/12V 6mm	187332	Alluminio	6 mm, ISO 4565/DIN 766	-	26 m/min	35 m/min	850 kg	800 W	19 kg	12 V	con campana	110	115
VER. V. X2 ALU 800W/12V 6mm	187332	Alluminio	6 mm, ISO 4565/DIN 766	-	26 m/min	35 m/min	850 kg	800 W	18 kg	12 V	basso profilo	110	115
VER. V. X2 CRO B+C 800W/12V 6mm	187332	Bronzo cromato	6 mm, ISO 4565/DIN 766	-	26 m/min	35 m/min	850 kg	800 W	23 kg	12 V	con campana	110	115
VER. V. X2 CRO 800W/12V 6mm	187332	Bronzo cromato	6 mm, ISO 4565/DIN 766	-	26 m/min	35 m/min	850 kg	800 W	21 kg	12 V	basso profilo	110	115
VER. V. X2 ALU B+C 1000W/12V 6mm	187333	Alluminio	6 mm, ISO 4565/DIN 766	-	20 m/min	40 m/min	1000 kg	1000 W	20 kg	12 V	con campana	117	150
VER. V. X2 ALU 1000W/12V 6mm	187333	Alluminio	6 mm, ISO 4565/DIN 766	-	20 m/min	40 m/min	1000 kg	1000 W	19 kg	12 V	basso profilo	117	150
VER. V. X2 ALU B+C 1000W/12V 10 3/8 HT	187333	Alluminio	10 mm, ISO 4565	-	20 m/min	40 m/min	1000 kg	1000 W	20 kg	12 V	con campana	117	150
VER. V. X2 CRO 1000W/24V 8-5/16"BBB-5/16"HT	187332	Bronzo cromato	8 mm, ISO 4565/DIN 766	14 mm, 3-legnoli	23 m/min	40 m/min	1060 kg	1000 W	23 kg	24 V	basso profilo	59	160
VER. V. X2 ALU B+C 1500W/12V 10 3/8 HT	187333	Alluminio	10 mm, ISO 4565	-	17 m/min	40 m/min	1200 kg	1500 W	25 kg	12 V	con campana	130	165
VER. V. X2 ALU B+C 1500W/12V 8-5/16"BBB-5/16"HT	187333	Alluminio	8 mm, ISO 4565/DIN 766	14 mm, 3-legnoli	17 m/min	40 m/min	1200 kg	1500 W	25 kg	12 V	con campana	130	165
VER. V. X2 ALU B+C 1500W/24V 10 3/8 HT	187332	Alluminio	10 mm, ISO 4565	-	19 m/min	40 m/min	1270 kg	1500 W	25 kg	24 V	con campana	65	175
VER. V. X2 ALU B+C 1500W/24V 8-5/16"BBB-5/16"HT	187332	Alluminio	8 mm, ISO 4565/DIN 766	14 mm, 3-legnoli	19 m/min	40 m/min	1270 kg	1500 W	25 kg	24 V	con campana	65	175
VER. V. X2 CRO 1000W/12V 6mm	187333	Bronzo cromato	6 mm, ISO 4565/DIN 766	-	20 m/min	40 m/min	1000 kg	1000 W	23 kg	12 V	basso profilo	117	150
VER. V. X2 CRO B+C 1000W/12V 6mm	187333	Bronzo cromato	6 mm, ISO 4565/DIN 766	-	20 m/min	40 m/min	1000 kg	1000 W	24 kg	12 V	con campana	117	150
VER. V. X2 CRO 1500W/12V 8-5/16BBB-5/16HT	187333	Chrome Plated	8 mm, ISO 4556/DIN 766	14 mm, 3-strand	17 m/min	40 m/min	1200 kg	1500 W	24 kg	12 V	Low Profile	130	165
VER. V. X2 CRO 1500W/12V 10 3/8 HT	187333	Bronzo cromato	10 mm, ISO 4565	-	17 m/min	40 m/min	1200 kg	1500 W	24 kg	12 V	basso profilo	130	165
VER. V. X2 CRO B+C 1000W/24V 10 3/8 HT	187332	Chrome Plated	10 mm, ISO 4565	-	23 m/min	40 m/min	1060 kg	1000 W	24 kg	24 V	With Drum	59	160
VER. V. X2 CRO B+C 1500W/12V 10 3/8 HT	187332	Bronzo cromato	10 mm, ISO 4565	-	17 m/min	40 m/min	1200 kg	1500 W	25 kg	12 V	con campana	130	165
VER. V. X2 CRO 1000W/24V 6mm	187332	Chrome Plated	6 mm, ISO 4565/DIN 766	-	23 m/min	40 m/min	1060 kg	1000 W	23 kg	24 V	Low Profile	59	160
VER. V. X2 CRO B+C 1000W/24V 6mm	187332	Chrome Plated	8 mm ISO 4565/DIN 766	-	23 m/min	40 m/min	1060 kg	1000 W	24 kg	24 V	With Drum	59	160
VER. V. X2 CRO 1500W/24V 8-5/16"BBB-5/16"HT	187332	Chrome Plated	8 mm, ISO 4565/DIN 766	14 mm, 3-strand	19 m/min	40 m/min	1270 kg	1500 W	24 kg	24 V	Low Profile	65	175
VER. V. X2 CRO 1500W/24V 10DIN766	187332	Bronzo cromato	10 mm, DIN 766	-	19 m/min	40 m/min	1270 kg	1500 W	24 kg	24 V	basso profilo	65	175
VER. V. X2 CRO B+C 1500W/24V 8-5/16"BBB-5/16"HT	-	Chrome Plated	8 mm, ISO 4565/DIN 766	14 mm, 3-strand	19 m/min	40 m/min	1270 kg	1500 W	25 kg	24 V	con campana	65	175
VER. V. X2 CRO B+C 1500W/24V 10 3/8 HT	187332	Bronzo cromato	10 mm, ISO 4565	-	19 m/min	40 m/min	1270 kg	1500 W	25 kg	24 V	con campana	65	175
VER. V. X2 ALU 1000W/12V 10DIN766	-	Anodised Αluminium	10 mm, DIN 766	-	20 m/min	40 m/min	1000 kg	1000 W	19 kg	12 V	Low Profile	117	150
VER. V. X2 ALU B+C 1000W/12V 10DIN766	187333	Anodised Aluminium	10 mm, DIN 766	-	20 m/min	40 m/min	1000 kg	1000 W	20 kg	12 V	With Drum	117	150
VER. V. X2 ALU 1500W/12V 8-5/16BBB-5/16HT	187333	Anodised Aluminium	8 mm, ISO 4565/DIN 766	14 mm, 3-strand	17 m/min	40 m/min	1200 kg	1500 W	24 kg	12 V	Low Profile	130	165
VER. V. X2 ALU 1500W/12V 10 3/8 HT	187333	alluminio	10 mm, ISO 4565	-	17 m/min	40 m/min	1200 kg	1500 W	24 kg	12 V	basso profilo	130	165
VER. V. X2 ALU 1500W/12V 10DIN766	187333	alluminio	10 mm, DIN 766	-	17 m/min	40 m/min	1200 kg	1500 W	24 kg	12 V	basso profilo	130	165
VER. V. X2 ALU B+C 1500W/12V 10DIN766	187333	Anodised Aluminium	10 mm, DIN 766	-	17 m/min	40 m/min	1200 kg	1500 W	25 kg	12 V	With Drum	130	165
VER. V. X2 ALU 1000W/24V 6mm	187332	Anodised Aluminium	6 mm, ISO 4565/DIN 766	-	23 m/min	40 m/min	1060 kg	1000 W	23 kg	24 V	Low Profile	59	160
VER. V. X2 ALU 1000W/24V 8-5/16BBB-5/16HT	187332	Anodised Aluminium	8 mm, ISO 4565/DIN 766	14 mm, 3-strand	23 m/min	40 m/min	1060 kg	1000 W	23 kg	24 V	Low Profile	59	160
VER. V. X2 ALU 1000W/24V 10 3/8 HT	187332	Anodised Aluminium	10 mm, ISO 4565	-	23 m/min	40 m/min	1060 kg	1000 W	23 kg	24 V	Low Profile	59	160
VER. V. X2 ALU 1000W/24V 10DIN766	187332	Anodised Aluminium	10 mm, DIN 766	-	23 m/min	40 m/min	1060 kg	1000 W	23 kg	24 V	Low Profile	59	160
VER. V. X2 ALU B+C 1000W/24V 6mm	187332	Anodised Aluminium	6 mm, ISO 4565/DIN 766	-	23 m/min	40 m/min	1060 kg	1000 W	24 kg	24 V	With Drum	59	160
VER. V. X2 ALU B+C 1000W/24V 10 3/8 HT	187332	Anodised Aluminium	10 mm, ISO 4565	-	23 m/min	40 m/min	1060 kg	1000 W	24 kg	24 V	With Drum	59	160
VER. V. X2 ALU B+C 1000W/24V 10DIN766	187332	Anodised Aluminium	10 mm, DIN 766	-	23 m/min	40 m/min	1060 kg	1000 W	24 kg	24 V	With Drum	59	160
VER. V. X2 ALU 1500W/24V 8-5/16"BBB-5/16"HT	187332	Alluminio	8 mm, ISO 4565/DIN 766	14 mm, 3-legnoli	19 m/min	40 m/min	1270 kg	1500 W	24 kg	24 V	basso profilo	65	175
VER. V. X2 ALU 1500W/24V 10 3/8 HT	187332	Alluminio	10 mm, ISO 4565	-	19 m/min	40 m/min	1270 kg	1500 W	24 kg	24 V	basso profilo	65	175
VER. V. X2 ALU 1500W/24V 10DIN766	187332	alluminio	10 mm, DIN 766	-	19 m/min	40 m/min	1270 kg	1500 W	24 kg	24 V	basso profilo	65	175
VER. V. X2 ALU B+C 1500W/24V 10DIN766	187332	alluminio	10 mm, DIN 766	-	19 m/min	40 m/min	1270 kg	1500 W	25 kg	24 V	con campana	65	175
VER. V. X2 CRO B+C 1000W/12V 10DIN766	187333	Bronzo cromato	10 mm, DIN 766	-	20 m/min	40 m/min	1000 kg	1000 W	24 kg	12 V	con campana	117	150
VER. V. X2 CRO 1000W/12V 10DIN766	187333	Bronzo cromato	10 mm, DIN 766	-	20 m/min	40 m/min	1000 kg	1000 W	23 kg	12 V	basso profilo	117	150
VER. V. X2 CRO B+C 1500W/12V 8-5/16"BBB-5/16"HT	-	Chrome Plated	8 mm, ISO 4565/DIN 766	14 mm, 3-strand	17 m/min	40 m/min	1200 kg	1500 W	25 kg	12 V	con campana	130	165
VER. V. X2 CRO 1500W/24V 10 3/8 HT	187332	bronzo cromato	10mm iso 4565	-	19 m/min	40 m/min	1270 kg	1500 W	24 kg	24 V	basso profilo	65	175

The "X" vertical windlasses are suitable for sail and motor boats from 6m to 27m in length. They have different motorization attributes according to each model.

The standard features that you can meet in every X series windlass are:

Watertight stainless steel ball bearing in the base (for better functionality and zero maintenance) which is a unique feature in the windlass market.
The clutch is made by two conical discs connected to the main shaft by two parallel planes on the shaft, in order to avoid using keys and allocate the weight load properly.
The electric motor and gearbox are connected by a particular coupling that is made by a socket for easier maintenance.
There is a sensor in the base and a magnet into the gipsy so they can be connected to a chain counter.
Manual override so that the chain or rope can be recovered manually in case of electric function failure.

Per scegliere il verricello più adatto, occorre determinare se il prodotto avrà un uso normale o intensivo, per questo motivo abbiamo creato una tabella che vi fornirà indicazioni sul prodotto più adatto a voi. Lo schema è da ritenersi puramente indicativo, per la scelta definita vi preghiamo di rivolgervi ad un professinista del settore che vi saprà fornire tutta l'assistenza necessaria. Windlass Selection Tool
