SX4- verricello verticale

Invia Ordine

[600033] KIT S SENSORE&MAGNETE X4

[630669] ALBERO X4 #934A

[631403] COPRI FRENO FALKON #507A CRO

[631517] CANOTTO X4 #877

[631535] Corona dentata X4-SX5 M=2,25 Z=84 #876

[631654] CORPO RIDUTTORE X4 #878 ALU

[631745] CUSCINETTO 6008 2RS #870

[631753] CUSCINETTO 6206 2Z #453

[631761] CUSCINETTO 16010 #396

[631924] DISTANZIALE X4 #883

[632087] FLANGIA X4 #874

[632141] FLANGIA X4 #880

[632158] FLANGIA X4 #881

[632171] FRENO SX3.5 #1236

[633298] MOTORE IDRAULICO KM20-8 R049S1 LEA/EA-N #433

[633429] MANOPOLA X4 #938

[633502] Lofrans Motore Titan 2300W/24V #419

[633503] Lofrans Motore X4 2700W/24V #433

[634871] Rondella DIN125 M8 A4

[635285] Staccacatena SX3.5 #1229

[636665] Stripper SX4 AISI 316

[635328] SALTARELLO X4 #399

[635696] VITE SENZA FINE X5 M=2.25 Z=84 #1261

[636355] BASE SX4 #2042/2048

[636365] COPRIBARBOTIN SX4 #2041

[636405] Volantino SX4 #2050 R/O

[636413] DISCO FRIZIONE INTERNO SX4 #2045

[636429] Campana SX4 INOX #2049

[636510] Giunto motore idraulico X4-SX4 #679

[636536] Disco Frizione Esterno SX4 Senza Campana

[636573] GYPSY-6 IMPR. CAT.12-13 DIN766 (NICHELATO) INOX

Main features:

Compact round base design
Marine AISI 316L stainless steel construction
With drum or low profile
Independent gypsy and drum operation
Manual chain release
Chain counter magnet pre-installed as standard
Ηeavy-duty electric motor
Anodised marine aluminium gearbox
Chain pipe available as an option

Standard Equipment:

Dual direction solenoid pack
Handle
Gypsy for chain
CD / Instruction manual
Chain pipe also available as an option, code 636313

Mettiti in contatto

Description	Tipo di motore	Tensione	Tiro Massimo Istantaneo	Carico di lavoro Massimo al sollevamento	Velocità di recupero a carico (m/min)	Velocità Max. di recupero	Peso netto modello a basso profilo (kg)	Interruttore magnetotermico	Pressione idraulica	Flusso idraulico	Tipo	Barbotin per catena	Senso di tiro a salpare	Carico di lavoro Massimo (A)	Net Weight with Drum (kg)
VERRICELLO V. SX4 INOX BASE TONDA B+C 2300W/24V 12-13DIN766	2300 W	24 V	2100 kg	500	13 m/min	25 m/min	72	-	-	-	With Drum	12 mm, ISO 4565/ 13 mm, DIN 766	CW	160	82
VERRICELLO V. SX4 INOX BASE TONDA B+C 2700W/24V 12-13DIN766	2700 W	24 V	2500 kg	530	13 m/min	28 m/min	75	-	-	-	With Drum	12 mm, ISO 4565/ 13 mm, DIN 766	CW	170	85
VERRICELLO V. SX4 INOX BASE TONDA 2300W/24V 12-13DIN766	2300 W	24 V	2100 kg	500	13 m/min	25 m/min	72	-	-	-	Low Profile	12 mm, ISO 4565/ 13 mm, DIN 766	CW	160	82
VERRICELLO V. SX4 INOX BASE TONDA 2700W/24V 12-13DIN766	2700 W	24 V	2500 kg	530	13 m/min	28 m/min	75	-	-	-	Low Profile	12 mm, ISO 4565/ 13 mm, DIN 766	CW	170	85
VERRICELLO V. SX4 INOX BASE TONDA HYD 12-13DIN766	Hydraulic - 8cc	-	2500 kg	650	16 m/min	16 m/min	55	-	200	32	Low Profile	12 mm, ISO 4565/ 13 mm, DIN 766	CW	-	60
VERRICELLO V. SX4 INOX BASE TONDA B+C HYD 12-13DIN766	Hydraulic - 8cc	-	2500 kg	650	16 m/min	16 m/min	55	-	200	32	With Drum	12 mm, ISO 4565/ 13 mm, DIN 766	CW	-	60
VERRICELLO V. SX4 INOX BASE TONDA B+C 2700W/24V R/O 14mm	2700 W	24 V	2500 kg	530	13 m/min	28 m/min	75	-	-	-	With Drum	14 mm	CW	170	85
VERRICELLO V. SX4 INOX BASE TONDA R/A 2700W/24V 12-13DIN766	2700 W	24 V	2500 kg	530	13 m/min	28 m/min	75	636091	-	-	Low Profile	12 mm, ISO 4565/ 13 mm, DIN 766	CCW	170	75
VERRICELLO V. SX4 INOX BASE TONDA R/A HYD 12-13DIN766	Hydraulic - 8cc	-	2500 kg	650	16 m/min	16 m/min	55	-	200	32	Low Profile	12 mm, ISO 4565/ 13 mm, DIN 766	CCW	-	55

The standard features that you can meet in every SX series windlass are:

Watertight stainless steel ball bearing in the base (for better functionality and zero maintenance) which is a unique feature in the windlass market.
The clutch is made by two conical discs connected to the main shaft by two parallel planes on the shaft, in order to avoid using keys and allocate the weight load properly.
The electric motor and gearbox are connected by a particular coupling that is made by a socket for easier maintenance.
There is a sensor in the base and a magnet into the gipsy so they can be connected to a chain counter.
Compact round base design constructed with Marine AISI 316L Stainless Steel

To select the proper anchor windlass, you must determine whether it's for a light or heavy use, so we have created a Windlass Selection Tool to help you. Please note that this tool offers recommendations; for your final windlass selection, your local distributor will be able to advise and assist you.
